◆產品的特征 Product features
1. 制作有趣,內(nei)部結(jie)構顏值(zhi),環保(bao)性目(mu)的好;
2. 可(ke)手(shou)動調節式漩風脫(tuo)離器,能將(jiang)可(ke)作研磨材料與細微有(you)害氣體脫(tuo)離,好的研磨材料再(zai)次的使用;
3. 包括(kuo)零零配件進行可信(xin)賴德國配件上的,利用時間長;
4. 制作加(jia)工(gong)產品表(biao)面(mian)上(shang)光滑;
5. 多車間工作臺制定;進行員可互相進行噴砂。要根據加盟商供需,待選擇手動操作時或自功 ;可按合作方條件定制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆適用于超范圍 Applicable scope
生態板材(cai),網(wang)上機(ji)殼(ke),影響表面面板,三文治烤盤等平(ping)面磨(mo)及方(fang)體(ti)零件的噴砂加工制(zhi)作。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆包括能力產品參數 Main technical parameters
|
機氣具體型號 Model |
STR-多工位輸送式噴砂機 |
|
機器長(chang)寬(kuan)高(gao) Complete machine size(mm) |
3000×1000×1700 |
|
辦公(gong)面積(ji) Work space(mm) |
2000×1000×800 |
|
外氣(qi)流輸送尺碼 Conveying the size(mm) |
500×1000×1000(2件(jian)) |
|
濾塵箱長寬 Dedust box sizes(mm) |
600×600×1800 |
|
破乳器(qi)直(zhi)流電機 Separator motor |
220V 50HZ 550W |
|
分離出(chu)來器(qi)新風量 Separator air volume |
8.5m3/min |
|
壓(ya)縮視頻空氣的源(yuan) Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明(ming) Floodlight |
兩盞30W防火燈 |
|
系統容量 Machine weight |
550kg |
